TC-2U60PD8
EOL - 600W 2U High Efficiency Switching Power Supply
- High Efficiency 82% minimum
- 17ms Hold Up Time
- Over Current Protection
- Over Voltage Protection
- Short Circuits Protection
Product Introduction
XEAL 2U power supply series provide high performance in compact form factor. The TC-2U60PD8 supports server, compact PC, and space constrained application. Standard feature includes high efficiency, triple circuits protection, and EPS 2U for industrial and high performance system requirement.
| Model Number | TC-2U60PD8 |
| RoHS Compliance | Yes |
| Output Wattage | 600 |
| Efficiency | 80% |
| Connector Type | Main Connector :: 20+4 pin 4+4pin 12V :: 1 8pin EPS 12V :: 1 6+2 Pin PCIE :: 1 Molex :: 4 SATA :: 4 Floppy :: 1 |
| Dimensions (WxHxD) | 3.94" x 2.76" x 9.45" 100.1 mm x 70.1 mm x 240.0 mm |
| Notes | - HTS code: 8504.40.6012 (ECCN: EAR99) |
Parts & Accessories
| Image | Accessory | Description |
|
ATC-44-12EXT | Build-to-Order - 4pin to 4pin 12V Extension Cable 12" |
|
ATC-2424-12EXT | Build-to-Order - 24pin to 24pin Extension Cable 12" |
|
ATC-88EPS-12EXT | Build-to-Order - 8pin to 8pin EPS Extension Cable 12" |
|
Output
FAQ
There are no FAQ entries for this model. |
