Product Detail

4U 12-bay SAS/SATA 12Gb/s SFF-8644 JBOD Trayless Hotswap Chassis

500W Power Supply
120mm x1 Cooling Fan
Power and HDD LED
Power and Alarm Reset Switch
Independent HDD Power Swtich
Supports SAS I/II/III and SATA I/II/III Hard Drives
Drive cage Integrative shaping aluminum design for best cooling
High Performance Transfer Rate up to 12Gb/s
Aluminum front bezel with metal key lock for double safety
Multi-functional LED Indication
Support Hot-Swap & RAID Configuration (need an additional RAID controller)

Product Introduction

JAGE412HD-DE-P is an external 4U-12 bay hot-swappable SAS/SATA rackmount disk array storage chassis. It provides users a most big storage capacity for up to 12 hard drives for RAID configurations. This 4U-12 Bay external SAS/SATA JBOD is designed with 3 high quality HD miniSAS (SFF8644) connectors. One 120mm ball bearing fan offers long lasting and enhanced thermal cooling solution. DAGE412UDE-3HD provides maximum storage and performance to high density storage system.

Specifications	Download	Optional Accessories
Output	FAQ
Compatible Chassis

Model Number	JAGE412HD-DE-P
RoHS Compliance	Yes
Dimensions (WxHxD)	19.00" x 7.00" x 20.00" 482.6 mm x 177.8 mm x 508.0 mm

Download

There are no downloadable media for this product.

Parts & Accessories


Accessory

Description

Output

There are no Power Output Specifications for this product.

FAQ

There are no FAQ entries for this model.
