Build-to-Order - 3U 16-Bay Storage Server Rackmount Chassis

Fiber Optical Drive Tray Status Indicator
Fully RoHS Compliance
Power + LAN + HDD LED Indicator
Front Access USB Connector
miniSAS (SFF-8087) 6Gb/s HDD Backplane with SGPIO
Support EATX Motherboard
Supports Both SAS/SATA Hard Drives
Sliding Rails Included
3x 120mm Hotswappable PWM Fans

Product Introduction

The EX storage server series rackmount not only has the stylish appearance, but the functionality and flexibility make EX series a new breed of storage server. As SAS and SATA technology has become a more cost effective solution, we have taken a step forward to prepare the migration of new technology and provide the mini SAS backplane to support both latest SAS and SATA hard drives, and also provide redundant power supply to ensure total up time of mission critical server applications.

Specifications	Download	Optional Accessories
Output	FAQ
Compatible Chassis

Model Number	EX3M16
RoHS Compliance	Yes
Dimensions (WxHxD)	19.00" x 5.25" x 27.10" 482.6 mm x 133.4 mm x 688.3 mm
Notes	- hard drive backplane requires 4 molex power connectors - a controller with at least four SFF-8087 or SFF-8643 connectors is required

Download

Data Sheet

Product Drawing

Parts & Accessories

Image	Accessory	Description
	K-SF87-75	miniSAS SFF-8087 75 cm Cable
	K-HD4387-50	HD miniSAS SFF-8643 to miniSAS SFF-8087 50 cm Cable
	K-HD4387R-50	HD miniSAS SFF-8643 to miniSAS SFF-8087 Right Angle 50 cm Cable
	K-SF87R-50	miniSAS SFF-8087 Right Angle 50 cm Cable

Output

There are no Power Output Specifications for this product.

FAQ

Q :	How to install the rail system?
A :	Please refer to the rail system TC-RAIL28-EX34 product page. http://www.istarusa.com/istarusa/products.php?model=TC-RAIL28-EX34
Q :	How to install 2.5" HDD/SSD?
A :	Please find the PDF file for more information.
Q :	Specifications of the 120mm PWM fan.
A :	The max. performance is 3600 RPM, 164.39 CFM, and 56.5 dBA.
Q :	Hard drive LED status
A :	Please refer to the PDF file.
