Product Detail

4U 8-bay SATA 6.0 Gb/s eSATA Hotswap Chassis

120mm Cooling Fan for Ventilation
LED Indicators for Power and Activity on Each Hard Drive
Supports 8x 2.5"/3.5" SATA 6Gb/s Hard Drives
Hot-swappable Both on Host and Device
Individual Lock of each HDD Tray for Physical Security
8x eSATA Connectors
Supports up to 6.0Gb/s Data Transfer Speed Per eSATA Connection

Product Introduction

DAGE408U40T7DE-ES is an external 4U-8 bay hot-swappable SATA rackmount disk array storage chassis. It provides users a most big storage capacity for up to 8 hard drives for RAID configurations. This 4U-8 Bay external SATA enclosure is designed with 8 eSATA connectors. One 120mm Ball bearing fan offer long lasting and enhanced thermal cooling solution. DAGE408U40T7DE-ES provides maximum storage and performance to high density storage system.

Specifications	Download	Optional Accessories
Output	FAQ
Compatible Chassis

Model Number	DAGE408U40T7DE-ES
RoHS Compliance	Yes
Dimensions (WxHxD)	19.00" x 7.00" x 20.00" 482.6 mm x 177.8 mm x 508.0 mm

Download

There are no downloadable media for this product.

Parts & Accessories

Image	Accessory	Description
	K-SF88XES-1M	miniSAS SFF-8088 to 4x eSATA 1 meter Cable
	TC-RAIL-20	20" Sliding Rail Kit for Most Rackmount Chassis
	TC-RAIL-24	24" Sliding Rail Kit for Most Rackmount Chassis
	TC-RAIL-26	26" Sliding Rail Kit for Most Rackmount Chassis
	CAGE-ESA2ESA	Build-to-Order - ESATA to ESATA External SATA Cable

Output

There are no Power Output Specifications for this product.

FAQ

There are no FAQ entries for this model.
