Product Detail

4U Compact Stylish Rackmount Chassis 8 x 3.5" Hotswap Drives PS2 PSU

Supports front access USB ports
Supports standard ATX PSU
Compatible with redundant power supplies
8 hot-swappable bays for 3.5" HDDs
Supports 3.5" SAS and SATA hard drives
Key lock front bezel to prevent unauthorized access

Product Introduction

D-416-B8SA is a reliable and stable 4U-high server chassis. The full size I/O supports all ATX motherboard with a Dual-core/ Quad-Core processors and the backplane supports 7 full-height add-on cards. This chassis is 21" deep and has optional three 80mm cooling fans in the center and two 60mm fans at rear for air ventilation. In addition, D-416-B8SA supports a standard ATX PS2 power supply to meet regular server system applications.

Specifications	Download	Optional Accessories
Output	FAQ
Compatible Chassis

Model Number	D-416-B8SA
RoHS Compliance	Yes
Dimensions (WxHxD)	19.00" x 7.00" x 21.77" 482.6 mm x 177.8 mm x 553.0 mm
Notes	- the two internal 3.5" bays at the bottom of drive cage cannot be used when an EATX motherboard is in place.

Download

Data Sheet

Parts & Accessories

Image	Accessory	Description
	TC-RAIL-26	26" Sliding Rail Kit for Most Rackmount Chassis
	TC-RAIL-24	24" Sliding Rail Kit for Most Rackmount Chassis
	TC-RAIL-20	20" Sliding Rail Kit for Most Rackmount Chassis

Output

There are no Power Output Specifications for this product.

FAQ

There are no FAQ entries for this model.
